| Product Description | |
| CPU | •Allwinner A64,quad Cortex-A53@1.2GHz |
| •32KB L1 instruction cache and 32KB L1 data cache, 512KB L2 cache | |
| GPU | •ARM Mali400MP2 GPU |
| •Support OpenGL ES 2.0 and OpenVG 1.1 standard | |
| ROM | •Support eMMC 5.0 |
| •Support boot from eMMC, 8bit data bus | |
| •Default 8GB, 8GB-64GB optional | |
| RAM | •1x256*32, LPDDR3 |
| •Default 1GB, 2GB optional | |
| SD/MMC | •Support TF card, SD3.0 |
| •Support 4GB-128GB | |
| •Suppport 8bit data bus | |
| Video Decoding | •Support H.264 1080p 60fps and H.265 4K 30fps decoding |
| •Support 1080p blu-ray 3D | |
| Video Encoding | •Support H.264 video encoding up to 1080p 60fps |
| •Support JPEG baseline: picture size up to 8182x8192 | |
| LCD | •7 inch 1024*600,8 inch ,10.1inch,800*1280 MIPI LCD,31Pin, the current backlight can be adjustable by jumper |
| •Support LVDS LCD,2*15PIN,1920*1080P, 30fps | |
| •Support eDP LCD,1920*1080P,30fps | |
| •Support HDMI V1.4 out, 1080P 30fps | |
| Touch Panel | •Support USB touch panel |
| •Support I2C COF touch,6PIN FPC 0.5mm pitch | |
| Audio Input and Output | •One micphone input |
| •One headphone jack, L&R | |
| •2*10W speaker | |
| •Buzzer optional | |
| USB | •Total 5xUSB, 1xUSB OTG, data transmission or ｕｐｄａｔｅ |
| •4xUSB host, one used for 4G module, rest can be used for host. | |
| TWI | •2xTWI, one used on with touch panel, one used for GPIO |
| •Support standard I2C device | |
| UART | •Support 4xUARTs |
| •UART0 for debug | |
| •UART2 only support TTL | |
| •UART3 and UART4 can support RS485 or RS232 | |
| GPS | •Onboard ST-26-Z8LR GPS module(Default NC) |
| •BDS/GPS/GLONASS | |
| •Accuracy 2.5 meter, Support AGNSS | |
| Ethernet | •One 100M RJ45 |
| •PoE Power Supply, 12V,30W,4Pin WF2.0 | |
| Key | •Support 6key from ADC |
| •One Power on/off key | |
| UBOOT | •Onboard UBOOT key |
| •Used for force upgrade | |
| 4G Module | •Support PCIe USB 4G module |
| •Default support EC20, CAT1 | |
| WIFI+BT | •8723DS WIFI+BT module, 2.4G, 802.11 b/g/n |
| •Bluetooth,V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.0 | |
| GPIOs | •Support 3xGPIO, It can be setting as input , output or interrupt |
| •3.3V power supply | |
| PWM | •2xPWM, one for MIPI LCD |
| •Support LVDS or eDP backlight | |
| Remote | •Remote key |
| •Support LED status for remote control | |
| Power | •12V, 2A power supply, DC inner hole 2.0mm |
| •WF2.0, 6PIN power supply(same with DC jack) | |
| OS | •Android 7.1 OS |
| •Kernel Version: 3.10.65 | |
| L*W*H | 135*85*10mm |
