RWB046 RK3399
Product DescriptionCPU•Rockchip RK3399,dual Cortex-A72 +Quad Cortex-A52, max 2.0...
Product Details
Product Description
CPU•Rockchip RK3399,dual Cortex-A72 +Quad Cortex-A52, max 2.0GHz
•48KB L1cache and 32KB L1 data cache for each A72. 32KB L1 for each A52
GPU•Mali-T860MP4, 256K L2 Cache
•Compatible with OpenGL ES1.1/2.0/3.0/3.1,
OpenCL and DirectX 11.1
ROM•eMMC 5.1
•Support boot from eMMC, 8 bit data bus
•Default 16GB, support from 8GB-128GB
RAM•2x256*32 LPDDR4
•Default 2GB
Video Decoding•Support H.264/AVC Base/Main/High/High10 profile@level 5.1: up to 4Kx2K@30fps
•Support H.265/HEVC, Main/Main10 Profile@level 5.1 High-tier: up to 4Kx2K@60fps
•Support VP9, profile 0, up to 4Kx2K@60fps
Video Encoding•Support video encoder for H.264 UP to HP@level4.1, MVC and VP8
•Support Image size is from 96x96 to 1920x1080(Full HD)
LCD•Dual Channel LVDS LCD, 1080P@60fps, Dupont dual 15pin
•LVDS RGB 30/24/18bit, frequency from 10Mto 148.5Mhz
Touch Panel•Support USB capacitive touch panel
•Support USB IR touch panel
•Support capacitive touch by I2C COF
Audio Input and Output•One headphone output, L&R
•Microphone input
•One amplifier, 12V, 15W
Video input•Support USB single or dual camera
•Max 1080P 60fps
SD/MMC•SD3.0,MMC 4.51
•Support 2GB/4GB/8GB/16GB/32GB
•4 bit data bus
USB•8xUSB, one OTG
•USB OTG port default as Host, it can be switch on Android System
•7xUSB host, PH2.0
TWI•2xTWI
•Support standard I2C device
UART•7xUART, Uart2 as debug UART
•Rest UART are TTL, PH2.0 4pin
Ethernet•One RJ45 100M ethernet
•On board transformer
WIFI+BT•AP6212 WIFI+BT module, 2.4G, 802.11 b/g/n
•Bluetooth,V5.2+EDR/BT v3.0/BT v3.0+HS/BT v4.0
Key•Uboot key on board for forced update
•Reset key on board
Fan•12V Fan and control
PWM•1xPWM
• Support LVDS backlight control
•LVDS backlight power 3.3V/5V/12V optional
•Support DC or PWM backlight control
Power•12V, 3A power supply,DC jack or PH connector
•DC jack 2.0mm ,PH2.5mm
•On board RTC batter, 3.0V
•Support watchdog
•Default heat sink
Others•Support WiFi+BT, WiFi b/g/n, BT4.1, AP6212 module
•Support one relay to control the door, 30V/2A
OS•Android 7.1 OS
•Kernel Version:
L*W*H140*80*11mm
