| Product Description | |
| CPU | •Rockchip RK3588,quad Cortex-A76 +Quad Cortex-A55, max 2.1GHz |
| •Quad-core Cortex-A76 and Quad-core Cortex-A55 share 3MB L3 cache | |
| GPU | •Mali-G610 MP4, 4x256K L2 Cache |
| •Compatible with OpenGLES 1.1, 2.0, and 3.2, OpenCL up to 2.2 and Vulkan1.2 | |
| NPU | • 6TOPs NPU, |
| •Supports INT4/INT8/INT16/FP16 hybrid operation and computing power | |
| ROM | •Support eMMC 5.1,5.0,4.5.1 protocol |
| •Support boot from eMMC, 8bits data bus width | |
| •Default 32GB, Support 64GB-256GB | |
| RAM | •2x32bits LPDDR4x |
| •Default 4GB, 8GB,16GB for optional | |
| Video Decoding | •Support Real-time Video decoder of MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC-1,VP9,VP8,MVC,AV1 |
| •Support MMU Embedded and Multi-channel decoder in parallel for less resolution | |
| •H.264 AVC/MVC Main10 L6.0: 8K@30fps(7680x4320) | |
| •VP9 Profile0/2 L6.1;H.265 HEVC/MVU Main 10 L6.1: 8K@60fps(7680x4320) | |
| •AVS2 Profile0/2 L10.2.6: 8K@60fps(7680x4320), AV1 Main Profile 8/10bit L5.3 4K@60fps | |
| •MPEG-1 and MPEG2 up to MP, VC-1 up to AP level 3 and VP8 version 2:1080p@60fps | |
| Video Encoding | •Support real-time H.265/H.264 video encoding |
| •Support up to 8K@30fps | |
| •Multi-channel encoder in paraller for less resolution | |
| LCD | •7inch 1024*600, 8inch, 10.1inch 31Pin, 800*1280 MIPI LCD, the current for backlight can be adjust by jumper. |
| •Support LVDS LCD, 2*15PIN, 1920*1080P, 60fps | |
| •Support eDP LCD,1920*1080P, 60fps,eDP 4K LCD | |
| •Support Vbyone LCD, 3840x2160@60Hz, eDP 4K LCD 3840x2160@60Hz | |
| •Support HDMI output, HDCP V2.3, 8K 60Hz | |
| Touch | •Support USB touch panel |
| •Support I2C COF touch panel, 6pin connector | |
| Audio Input and Output | •One Mic input |
| •One headphone jack, L&R, four-part form | |
| •10W amplifier, L&R | |
| Video Input | •Support one HDMI input, HDMI 2.0 RX, V2.0 2160P@60Hz, V1.4 3840x2160@Max 30Hz |
| •Support one MIPI CSI input, 40PIN, with HDR | |
| SD/MMC | •Support TF, compatible with SD3.0, MMC v4.51 |
| •Support 8GB-128GB | |
| •Support 8bits data bus width | |
| Storage | •Support TF card |
| •Support 3.5” or 2.5” HDD, 2.0 4PIN 5V, 12V power supply | |
| •Support M.2 mSATA | |
| USB | •Total 9xUSB, one USB 3.0 Support OTG, ｕｐｄａｔｅ, data transmission. |
| •One Type C, support PD3.0 fast charge, max 100W | |
| •One USB host, type A | |
| •6xUSB Host, WF2.0, 4PIN | |
| GPS | •ST-26-Z8LR GPS module as optional(Default NC) |
| •BDS/GPS/GLONASS | |
| •Positional accuracy 2.5 meter, Support AGNSS. | |
| TWI | •2xTWI, one used for touch panel, another one used on UART3 |
| •Support different kinds of external devices for standard I2C | |
| UART | •Support 6xUARTs |
| •UART2 for debug only | |
| •UART6 and UART7, support TTL or RS485 | |
| •UART3, UART5 and UART8 support TTL only | |
| Ethernet | •Support one GMAC |
| •On board transformer, RJ45 connector with indicator | |
| 4G/5G Module | •Support PCIe USB 4G module |
| •Default support EC20, CAT1 | |
| •Support M.2 5G module(M.2 SATA or M.2 5G module alternative) | |
| WiFi+BT | •RTL8852BE PCIe WiFi+Bluetooth module, 2.4G+5G,WIFI6 |
| •WiFi, IEEE802.11a/b/g/n/ac/ax, dual WiFi antenna | |
| •Bluetooth, BT5.2, Bluetooth v2.1+EDR, single antenna | |
| Keys | •U-boot key onboard |
| •Support ADC 6 key. With independent one power Key, it support 5 or 7 keys product | |
| •Support IR key | |
| PoE | •Support external PoE module power supply, 12V, 30W |
| •4PIN WF2.0 connector | |
| GPIOs | •Support 5xGPIO, it can be configured as input or output |
| •Default 3.3V, 5V or 12V can be offered by other connector | |
| PWM | •Support 2xPWM, one used for MIPI and LCD DC backlight |
| • Another used for LCD BL PWM | |
| Port | •LED indicator for power on and system working |
| •Micro SIM slot | |
| •One IR remote port, support LED indicator | |
| •GPS antenna port,WIFI+BT antenna port(2xWIFI+1xBT), IPEX-I | |
| Power | •12V, 3A power supply, inner 2.0mm for DC jack |
| •WF2.0 port, 6PIN | |
| OS | •Android 12 |
| •Kernel Version: 5.10 | |
| L*W*H | 140*80*11mm |
