| Product Description | |
| CPU | •Allwinner A64,quad Cortex-A53@1.2GHz |
| •32KB L1 instruction cache and 32KB L1 data cache, 512KB L2 cache | |
| GPU | •ARM Mali400MP2 GPU |
| •compatible with OpenGL ES1.1/2.0/3.0/3.1, OpenCL and DirectX 11.1 | |
| ROM | •Support 64 bit ECC per 512 or 1024 bytes |
| •Support8 bit data bus, Support 4GB, up to 64GB | |
| •Support boot from eMMC Flash | |
| RAM | •Support LPDDR3, default 1GB |
| •Support 32bits data bus width,Max 667MHz | |
| Video Decoding | •Support H.264 1080p 60fps and H.265 4K 30fps decoding |
| •Support 1080p blu-ray 3D | |
| Video Encoding | •Support H.264 video encoding up to 1080p 60fps |
| •Support JPEG baseline: picture size up to 8182x8192 | |
| Camera | •Support one CMOS camera |
| CSI max 1080p@30fps | |
| •Support BT656 | |
| •Support 8bit YUV422,8bit BT656 | |
| Display | •SupportCPU/RGB/LVDS/MIPI LCD |
| •LVDS max 1366*768@60fps, RGB 1920*1200@60fps | |
| •Support1/2/4-lane MIPI DSI 1920*1200 resolution LCD | |
| •SupportRGB666, RGB565,RGB888 | |
| •SupportHDMI V1.4, 1080P output | |
| Touch panel | •Support I2C capacitive touch |
| ••Support resistive touch by extended IC or USB. | |
| HDMI Out | •One HDMI 1.4 TX interface, supporting HDCP1.4 |
| •Supports 3840x2160 30fps | |
| Audio | •Two I2S/PCM |
| •Support I2S two input and output | |
| •One headphone out, one micphone input | |
| SD/MMC | •Support SD V2.0, eMMC V5.0, SDIO V3.0 |
| •SupportSD,SDIO 1 or 4 bus width | |
| •MMC Support 1/4/8 bus width | |
| USB | •Total 2xUSB, 1xUSB 2.0 OTG,1xUSB host |
| •Support high speed 480-Mbps, full speed12-Mbps, low speed 1.5Mbps | |
| SPI | •Max 2*independent SPI controller |
| •Master/Slave can be switch | |
| TWI | •Max 4*TWI |
| •Support fast mode(400Kbps) | |
| UART | •Max 6* UART |
| •Uart0 for debug | |
| •Speed up to 3MHz | |
| EMAC | •Support 10/100/1000 Mbit/s data transfer rates |
| •Support RMII/RGMII PHY interface | |
| •Support full-duplex and half-duplex operation | |
| LRADC | •One ADC,6 bit resolution, one ADC max support 7 key |
| •Voltage range is 0V-2V | |
| PWM | •2* PWM output |
| • Pre-scale 1 to 16 adjustable | |
| Security | •Support AES, DES, 3DES |
| •Support ECB/CBC/CTR modes for AES/DES/3DES | |
| •SupportAES 128-bits,192-bits and 256-bits | |
| PMU | •Onboard AXP223 PMU, 3.5V-7V input,QFP68 |
| •Support one DCDC, DC-DC1 1.6-3.4V@1.5A; | |
| •Support five LDO, DLDO2/2 0.7V-3.4V@400mA;DLDO3 0.7V-3.3V@300mA;DLDO4 0.7V-3.3V@500mA;ELDO2 0.7V-1.9V@200mA;ELDO3 0.7V-1.9V@200mA | |
| •Support RTC power supply,30mA | |
| •Support 4.1V/4.2V/4.22V/4.24V Li-on Battery | |
| •Charging current max to 2.8A | |
| •Support charging management, OCP, OVP | |
| OS | Android 7.0 |
| L*W*H | 40*60*3.7mm |
